Direct Imaging System for Next-Generation Patterning

Direct imaging equipment for
patterning suitable for
advanced package such as FCCSP,
FCBGA and FOPLP

World-leading imaging of 5 um

LeVina combines superior imaging heads equipped with our proprietary GLVTM optical engine and laser control technologies that utilize an optical system featuring more of our unique expertise. This new system is specifically designed for mass production and enables direct imaging of substrates at a market-leading resolution of 5/5 um. It will continue to deliver high-definition patterning of advanced packages even as they become increasingly miniaturized.

World-leading imaging of 5 um

High speed mass production

Throughput of 100 substrates per hour with L/S = 5/5 um

LeVina is fitted with an extremely reliable multi-head system and stage capable of moving at up to 480 millimeters per second. Alignment marks are read during scanning, allowing outstanding throughput regardless of the number of marks in the scanning direction (can also be automated). These features enable high resolution processing of 100 substrates (510 x 515 mm) per hour at L/S = 5/5 um.

Scan alignment

Low running costs

Thanks to the laser diodes used in its light source, LeVina cuts operating costs by around 70% compared to our DW-6000 system.

Improved cleanness

With LeVina, sources of particle generation have been blocked and it has been equipped with airflow control technologies that have a proven record in cleaning equipment for the semiconductor market. These advances have reduced contamination inside the system, helping to significantly improve yields.

This product is handled by SCREEN HD.
